STANDARD CONSTRUCTION
• FRAME:
Extruded Aluminum 6063-T5, 5/64" Thick & 4" Depth.
• BLADES:
Formed Aluminum 16 Gauge Thick, with
22 Gauge Perforated Aluminum Sheet Interior surface that covers insulation.
• BLADE CENTERS:
3-1/4" Centers at head and sills, Corrosion resistant steel fasteners used at assembly.
• INSULATION:
Fiber Infill which complies with class 0 building regulation. The infill has a glass cloth facing and is contained behind the perforated sheet. This dual protection prevents damage and fiber erosion and up to 100ft/s airway velocity.
• SCREEN:
Bird Screen 1/2"X1/2" Aluminum (Optional)
Aluminum 18 X 16 mesh corrosion resistant (Optional)
• FINISH:
Mill finish (Standard)
Anodize (Optional)
All RAL color (Optional)
• SIZES:
Minimum Width: 16"
Minimum Height: 16"
Maximum Single Section:
Width 120" x Height 120"
• Multiple Section:
Unlimited
