STANDARD CONSTRUCTION
• FRAME:
Extruded aluminum 2mm (5/64”) Thick & 75mm (3”) Depth.
• BLADES:
Extruded aluminum 2mm (5/64“) Thick
• BLADE CENTERS:
75mm (3") maximum centers to center corrosion resistant steel fasteners used at assembly.
• SAND DRIP:
Extruded aluminum 1.6mm (1/16“) Thick.
• FILTER:
Aluminum washable filter 25mm (1”) or 50mm (2”) Thick (Optional)
• FINISH:
Mill Finish (Standard)
Anodize (Optional)
All RAL color (Optional)
• FLANGE:
30mm Extruded aluminum flange (Optional)
50mm Extruded aluminum flange (Optional)
• WIRE MESH:
- Galvanized Bird Screen (STD)
- Aluminum Bird Screen
- Stainless Steel Bird Screen
- Galvanized Insect Screen
- Aluminum Insect Screen
- Stainless Steel Insect Screen
• SIZES:
Minimum Width: 12"
Minimum Height: 12"
Maximum Single Section:
Width 144" x Height 92"
Width 92" x Height 144"
Maximum Single Section Area: 13248 In
Multiple Section: Unlimited
