APPLICATION
Duct Access Door provides a practical and easy means of gaining access to components inside of round ductwork.
STANDARD CONSTRUCTION
• FRAME:
- Constructed from 24 Ga (0.7 mm) Galvanized Steel provided with Gasket all around.
• DOOR:
- Constructed from 22 Ga (0.8 mm) Galvanized Steel, double skin type with 1” (25 mm) fiber insulation.
• ATTACHMENT:
- Continuous Hinges for model K60-RHAD.
• LOCKS:
- Galvanized cam locks:
• FINISH:
- Mill Finish.
• SIZES:
- Minimum Size: 4”x4” (101.6x101.6 mm)
- Maximum Size: 24”x24” (609.6x609.6 mm)
- Minimum Duct Diameter = Height - 1”
OPTIONS
• Stainless Steel Construction.
• 2” (50 mm) fiber insulated door depth with 22 Ga (0.8 mm) frame thickness.
• Without Insulation.
• 20 Ga (1 mm) or 18 Ga (1.25 mm) door thickness.
• With Copper or Galvanized Handle.
